Stellite alloy valve sleeves are widely used in the field of petroleum drilling. The working environment and conditions of the petroleum drilling industry are extremely harsh. Specifically, water, various gases, wax, sand and other highly corrosive substances are usually present in sand-producing wells, heavy oil wells and high-pressure anti-condensate gas wells. Oil well pumps are required to extract oil from formations hundreds or even thousands of meters deep, which imposes stringent requirements on their components for excellent sealing performance, wear resistance and corrosion resistance. Stellite alloy valve sleeves manufactured by atmospheric pressure precision casting, vacuum precision casting and powder metallurgy processes can fully meet the above harsh service requirements.
زمینههای کاربردی
Stellite alloy valve sleeves are mainly used in valves such as ball valves, oil well pump valves and fluid valves.
مزایا و خدمات
Our company adopts precision casting and powder metallurgy processes for the mass production of valve sleeve products. These products feature stable performance and a long service life, which helps reduce equipment downtime and lower maintenance costs.
| درجه | سی | منگنز | کروم | نیکل | مو | دبلیو | آهن | شرکت | چگالی/گرم/سانتیمتر مکعب | سختی/HRC |
| استلایت ۱ | ۲.۰ تا ۲.۸ | 1.0 | ۲۹ تا ۳۳ | 3.0 | 1.0 | ۱۱.۰ تا ۱۴.۰ | 3.0 | بال | 8.55 | ۵۱ تا ۵۵ |
| Stellite 3 | 2.0～2.7 | 1.0 | ۲۹ تا ۳۳ | 3.0 | 1.0 | ۱۱.۰ تا ۱۴.۰ | 3.0 | بال | 8.55 | ۵۱ تا ۵۵ |
| Stellite 4 | 0.8～2.7 | 1.0 | ۲۸ تا ۳۲ | 3.0 | 1.5 | 12.5～15.5 | 3.0 | بال | 8.65 | 40～54 |
| Stellite 6 | 0.9～1.4 | 1.0 | 27～31 | 3.0 | 1.5 | 3.5～5.5 | 3.0 | بال | 8.30 | 38～44 |
| Stellite 6K | 1.4～1.9 | 1.0 | 27～31 | 3.0 | 1.5 | 3.5～5.5 | 3.0 | بال | 8.30 | 43～47 |
| استلایت ۱۲ | ۱.۱ تا ۱.۷ | 1.0 | ۲۸ تا ۳۲ | 3.0 | – | ۷.۰ تا ۹.۵ | 3.0 | بال | 8.40 | ۴۴ تا ۴۹ |
| Stellite 19 | 1.5～2.1 | 1.0 | 29.5～32.5 | 3.0 | – | 9.5～11.5 | 3.0 | بال | 8.45 | 46～51 |
| Stellite 20 | 2.2～3.0 | – | 30～34 | 3.0 | 1.0 | 14～19 | 3.0 | بال | 8.70 | 56～60 |
| Stellite 21 | 0.2～0.3 | 1.0～2.0 | 26～28 | 3.0 | 5.0～6.0 | – | 2.5 | بال | 8.33 | 27～40 |
| Stellite 31 | 0.45～0.55 | 1.0 | 24.5～26.5 | 3.0 | 0.5 | 7.0～8.0 | 2.0 | بال | 8.60 | 30～35 |
| Stellite 694 | 0.8～1.2 | – | 26.5～29.5 | 3.0 | – | 18.0～20.0 | 3.0 | بال | 8.7 | 47～51 |
