PC103-I21-C10-EU is a high-performance heat shrink machine suitable for carbide and high-speed steel cutting tools with shank diameters of Ø 3-32 mm.
Upgradeable to a 20KW HD heating coil for heating heavy-duty heat shrink knife handles up to
Ø 50 mm in diameter (optional)
– Intelligent NG coil
– Length pre-adjustment unit with height stop
– Single support type
– With contact cooling
– Includes cooling controller
– Includes rapid cooler (voltage: 230V, 16A)
– Includes two precision support bases
Includes two precision support trays
– Includes storage box – Must be ordered separately with specific model number – Power: 13 kW
– Main power supply: 3×400-480V, 16 A
| Description | Details / Specifications |
|---|---|
| Network Compatibility & Industry 4.0 | Ready for Industry 4.0 & Network Integration |
| User Interface | 7″ Touchscreen with Latest Software for Simplified Operation |
| Hệ thống làm mát | Specially designed for shrink chucks and thin-walled tool holders; ensures perfect fit |
| Heating Unit | Intelligent 13 kW Automatic Coil VS32-M |
| Cooling Method | External aerosol cooling unit for fast and clean cooling of all shrink chucks and sleeves |
| Temperature Control | Independent external air cooling unit with temperature control |
| Cooling Cap | Pneumatic cooling hood with “Touch-to-Release” function |
| Process Control | Scanner reads QR codes on tool holders for simple, automatic retrieval of shrinking parameters |
| Length Pre-setting | Length Pre-setting Device (Optional) |
| Tool Material & Range | Tungsten Carbide and HSS, Diameter range from Ø 3 – 32 mm |
| Main Power Supply | 3 x 400 – 480 V, 16 A |
| Power | 13 kW |
| Air Supply | Compressed air pressure of at least 4 bar |
